Choosing the right indoor PIR detector: A guide to the OPTEX FlipX Series

One of the most distinctive features of the FlipX series is its rotatable lens. With a simple 180-degree turn, installers can change the detection pattern without swapping out the device:
•    85° wide-angle detection: ideal for open spaces such as homes, offices, shops or warehouses.
•    5° narrow detection: perfect for corridors, entrances, windows, sliding doors or specific pass-through zones.

This turns FlipX into a genuine "two-in-one" sensor, adaptable to different requirements using a single model, while mountable at heights of up to 3 metres for further versatility. For installers, this means simpler project planning, and easier on-site adjustments when real-world conditions call for a change in configuration. In addition, this also reduces the need to stock multiple sensors as one device fits multiple applications, saving both time and cost.

One of the main challenges in indoor detection is balancing sensitivity and stability: a detector must identify a genuine intrusion while avoiding unwanted triggers from environmental factors or pets. FlipX incorporates a bespoke pyroelectric element developed by OPTEX that improves the sensor's ability to interpret thermal signals and distinguish between different types of movement. Unlike simply lowering sensitivity, which can hurt overall performance, FlipX detectors create human-sized detection areas and are able to detect target with much greater precision, delivering reliable human detection alongside excellent pet immunity.

FlipX's precision is further supported by OPTEX's proprietary SMDA (Super Multi-Dimensional Analysis) technology, which processes different signal patterns and environmental data to identify potential sources of false alarms, such as temperature changes, lighting variations, shadows or vegetation sway. The philosophy is simple: a security system shouldn't react to every change, but should recognise what genuinely represents a threat. This intelligent processing gives FlipX greater operational stability and more confidence for both end users and installers.

Installation is simplified by a removable terminal block, allowing wiring and replacement without accessing the main unit, and a built-in EOL resistor socket compatible with OPTEX's Plug-in End of Line Units (PEUs). This removes the need to fit separate resistors by hand, a common source of wiring errors and lost time, especially when working across control panels from different manufacturers with different resistance requirements.

The FlipX Standard offers an affordable, compact solution for homes and small businesses, certified to EN50131 Grade 2. Its discreet design integrates easily into most interiors, and the pyroelectric element, SMDA logic and pet immunity combine for reliable everyday protection. A clearly visible LED also makes walk-testing quick during commissioning. FLX-S models offer wide detection up to 12 m (85°) and narrow detection up to 18 m. Choose this range for cost-effective, easy-to-install protection in lower-risk environments.

The FlipX Professional is built for greater detection range and coverage, certified to EN50131 Grade 2. A double conductive shielding lens ensures reliable performance in direct sunlight or other interference. FLX-P models offer wide detection up to 15 m (85°) and narrow detection up to 24 m. Choose this range for shops, offices and warehouses where coverage area and resilience to interference are key.

The FlipX Advanced is certified to EN50131 Grade 3 and delivers advanced functionality for high-rick applications. Anti-masking protection triggers a trouble signal if the detector is deliberately obstructed, plus a super-high sensitivity mode for accurate detection even when the temperature difference between a person and the background is minimal. FLX-A models offer wide detection up to 15 m (85°) and narrow detection up to 24 m. This range suits banks, financial institutions, restricted areas and any site where protection must meet stricter, standards- or insurance-driven requirements.
