Product Details

The REDWALL SIP-IP-BOX is a series of long range IP/PoE outdoor PIRs designed to work in conjunction with Video Management Software (VMS) platforms, and IP camera manufacturers and PSIM providers. The alarm event generated by the IP sensors will trigger a response from the security system. Very stable in outdoor environment the Redwall SIP sensors have a very low false alarm rate and are instrumental for make event-triggered security systems stable. The SIP-5030-IP offers wide angle detection for large outdoor areas, covering 50x30m and has an intelligent detection system that automatically adjusts the sensitivity to the environment.

Enhancing IP CCTV systemsWeather and vandal-resistantVMS integration
Event-triggered CCTV systems need to rely on accurate and genuine detection. Although most IP cameras provide video motion detection, using this detection method alone can prove challenging in outdoor environment where the constant changes of lighting and weather conditions can create false alarmsREDWALL SIP PIRs are designed to be used in harsh outdoor environment, their sensitivity are adjusted automatically to the ambient temperature and illuminance, they feature an IP65 rating for the main unit. The SIP series is vandal-resistantant all SIP products are built with polycarbonate housing, featuring an accelerometer to detect whether or not the sensor position has been tampered with.
The REDWALL SIP-IP-BOX series generates a unique alarm event code (REC) which communicates a number of events including detection, tamper and environmental status to the IP cameras, DVR and VMS platforms that have integrated the code. The list of VMS plaforms that have already integrated our event code includes many key players in the industry and is constantly growing.


Applications

  • Buildings
  • Perimeter

Key Features

  • Double Dual/one Quad pyro-elements with patented Double Conductive Shielding
  • Advanced detection algorithm
  • Reinforced polycarbonate housing
  • Equipped with anti rotation & anti-masking functions to prevent vandalism

Downloads

FAQs

Once the Redwall SIP unit is mounted on the wall or a pole, ideally at a height of 4m – or at least above 2.3m, the View Finder should be plugged onto the sensor using the two holes to secure it. The correct viewing plate should be inserted – each SIP model has a corresponding viewing plate. Looking through the plate, the sensor should be adjusted to ensure that it is grounded at the maximum detection distance. For instance, for a SIP-3020, the sensor should be grounded (not directed towards the sky) at 30m. Additionally, it is best to avoid having the detection area right at the edge of the security area, rather it is best practice to leave 1m either side. If the detection area is 20m wide, it is better to centre the view at 11m from the edge on either side. If required, masking sticks can be used to mask part of the detection area. Watch our video tutorial

The detection will be less accurate. Ensure that the SIP is not installed higher than the recommended height which is 4m.

View all FAQs
