Sl  Qdm

Product Details

The SL-350QDM is a 100m outdoor active infrared (AIR) hardwired beam set designed for perimeter security. The Quad beam set features four selectable channels making it easy to stack in beam towers as well as dual modulation and power auto-adjustment to provide a highly reliable signal transmission between receiver and transmitter even when exposed to strong sunlight or harsh weather conditions. It can also be connected to an IP network when used in conjunction with the IP/POE module PIE-1.

Easy alignment Weather resistant
A perfect alignment between transmitter and receiver is key to optimise the operation of the active beams. To make the optical alignment easier, the SL-350QDM chassis features vivid yellow colours to be seen from the distance and the "Sniper Viewfinder", a telescopic lens magnifying twice the distance inside the beam. A sound gauge fitted in the receiver validates the accuracy of the optical alignment. For the fine tuning, the SL-QDM transmitter and receiver are both fitted with five LEDs to indicate the level of the signal received from the transmitter ranging from poor to excellent. IP65 rated, the SL-3500QDM housing has been designed to resist both water and dust. The two hoods featured on the front cover are positioned over the upper and lower beam to prevent frost from attaching to the cover and potentially affecting the signal power. The housing is made of UV resistant polycarbonate material to avoid deterioration caused by ultraviolet rays and maintain good transparency for the infrared beams over time. Additionally, the beams are fitted the light disturbance compensation circuit differentiates the beam signal from other external light sources.

Applications

  • Perimeter
  • Roof / Ceiling
  • Garden
  • Driveway

Key Features

  • Aspherical lenses
  • Including LED and sound gauge
  • Stackable model
  • Dual-mod & power auto adjust.
