VXI-DAM Outdoor 90-degree dual-tech PIR with antimasking

12m dual-tech for approach detection
Digital signal analysis to greater reliability
End of line resistors option
active infrared antimasking

Contact

Where to Buy

Residential

Warehouse

Garden

Retail

Commercial

Education

The following table indicates the areas of intended use of the equipment and any known restrictions. For countries not included in this table, please consult the responsible Spectrum Management Agency.

Microwave emission power

Countries

10.525GHz (X5 version)

Belgium, Denmark, Germany, Greece, Iceland, Italy, Luxembourg, The Netherlands, Norway, Spain, Sweden, Switzerland

10.587GHz (X8 version)

France, Ireland, United Kingdom

13.700 GHz

Austria, Czech Republic, Finland, Slovakia

Swipe to view

Specifications

See details

Details

Product Range

VX Infinity Series

Model Code

VXI-DAM

Detection method

Passive infrared & Microwave

Detection Coverage

12.0 m (40 ft) wide / 16 zones

Detectable speed

0.3 – 1.5 m/s (1 - 5 ft/s)

Sensitivity

2.0°C (3.6°F) at 0.6 m/s (2 ft/s)

Power input

9.5 – 18 VDC

Current draw

35 mA (max) at 12 VDC

Alarm period

2.0 ±1.0 sec.

Warm-up period

Approx. 60 sec. (LED blinks)

Alarm output (R)

N.C. / N.O. Selectable 28 VDC 0.1 A (max)

Trouble output

N.C., 28 VDC 0.2 A max.

Tamper output

N.C., 28 VDC 0.1 A max.

LED indicator

Red: Warm-up, alarm,masking detection. Yellow: Warm-up, MW detect.

Operation temperature

-20 – +45°C (-4 – +113°F)

Relative humidity

95% max.

Installation Method (indoor/outdoor)

Outdoor

Mounting height

0.8 - 1.2 m (2'7" - 3'11")

Weight

600 g (17.7 oz.)

Accessories

Screw (4×20 mm) ×2 , Wiring sponge ×3 , Masking seal ×3

Security Grade

IP55
