Product Details

The VXI-CMOD is a wireless HD camera module with 180° panoramic angle for real-time day and night visual verification of VX Infinity alarm activations. VXI-CMOD can be retro-fitted onto any existing hardwired VXI models (VXI-ST, VXI-AM, VXI-DAM), fitting snugly on top. When the sensor detects an intruder, the camera module is activated: it records the event and sends a notification through an app called “OPTEX Vision” to the paired mobile phone(s) so the owner or property carer can access the live view and take the appropiate action.

Taking outdoor detection to another level

Discover VXI-CMOD product benefits

A flexible security solution with or without control panel

VXI-CMOD provides a visual verification solution which doesn't require connection to an alarm panel and where security can conveniently be monitored from a smartphone application, OPTEX Vision App. Via the App push notifications can be enabled or disabled and several users can simultaneously access the live view and stored videos as well as share the recordings.

Be notified only when it matters

VXI-CMOD is led by OPTEX's best-selling outdoor intrusion sensor, VX Infinity, providing very reliable detection. The sensor features sensing analytics and is small animal tolerant so you are not bothered by nuisance false alarms every time it rains, pets are out in the garden or an insect is crawling on the lens.

Verify if it is really an intrusion

Through the App the owner(s) or property carer's will be immediately notified and can access the live camera view and a 30 second video (2 seconds pre-alarm and 28 seconds post-alarm) to determine if its a real intrusion. Through the App users can also enable/ disable the audio to listen in and get more information.

Important notice: Please use a microSD card with a maximum memory of 32GB and with FAT-32 format. Memory cards above 32GB can weaken the performance of VXI-CMOD.

VXI-CMOD Firmware ver. 1.2.2.12

A simple firmware update will upgrade your VXI-CMOD camera module so you can take advantage of the new RTSP feature and stream the live view to your existing security system, being an alarm panel or NVR..

A simple firmware update will upgrade your VXI-CMOD camera module so you can take advantage of the new RTSP feature.

DOWNLOAD LATEST FIRMWARE

FAQs

Please view the following video or download the guide attached with a step by step guide on how to install the VXI-CMOD.

Please use a microSD card with a maximum memory of 32GB and with FAT-32 format (can be formatted with OPTEX Vision App).

Yes, with the RTSP protocol (Real Time Streaming Protocol).

The VXI-CMOD doesn’t need an alarm control panel, only a WIFI router and internet connection. You can manage it via the OPTEX Vision App, which allows to access the live stream and audio, get notifications of the alarm activations, see and share the recorded videos.

OPTEX Vision App is the dedicated App for VXI-CMOD. It is compatible with Android and iOS and can be downloaded for free from Google Play or the App store. Quick guide to the installation and set-up of the OPTEX Vision App can be found in the following videos.
